Central electrical unit

Lighting wiring harness

Assembly diagrams

9 diagrams

Parts

31 parts

5N0971071 Offers

[Name] [Note] [QTY]
wiring harness section for lighting left 1
5N0971071A Offers

[Name] [Note] [QTY]
wiring harness section for lighting left 1
for vehicles with gas discharge bulb
5N0971071K Offers

[Name] [Note] [QTY]
wiring harness section for lighting left 1
Replacements: 5N0971071AB
5N0971071L Offers

[Name] [Note] [QTY]
wiring harness section for lighting left 1
for vehicles with gas discharge bulb
Replacements: 5N0971071AC
7H0941165 Offers

[Name] [Note] [QTY]
Flat contact housing with contact locking mechanism 2 pin 1
black
for fog lamp
Possible single wire:
000979244E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat contact with retaining lug 2,8
3D0972741 single wiring seal 6,35X5,8MM 1
seal ring 2 point
light brown
for wire cross section: 2,5QMM
5N0971073B Offers

[Name] [QTY]
part section wiring harness 1
Front frame
5N0971073 Offers

[Name] [QTY]
part section wiring harness 1
Front frame
4D0971992 Offers

[Name] [Note] [QTY]
Flat connector housing with contact locking mechanism 2 pin 1
black/violet
Signal horn
Possible single wire:
000979016E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
flat contact 2,8
000979141E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979237E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 2,5 X
-40C/+105C
flat contact 2,8
000979237EC 1 set single wires each with 2 silver-plated contacts, in bag of 5 'Order quantity. 5' X
-40C/+125C
with cable crosssection: 2,5
flat contact 2,8
1J0973702 Offers

[Name] [Note] [QTY]
Flat contact housing with contact locking mechanism 2 pin 1
black
Lid lock
mating connector
1J0973802 Flat connector housing with contact locking mechanism 2 pin 1
black
Possible single wire:
000979019E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
flat contact 1,5
000979019EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
flat contact 1,5
000979038EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+105C
flat contact with retaining lug 1,5
000979038FA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
flat contact 1,5
(Copper wires galvanised)
000979131E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 1,5
000979131EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 1,5
000979253E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,5 X
-40C/+125C
flat contact 1,5
1J0973814 Offers

[Name] [Note] [QTY]
Flat contact housing 8 pin 1
Coupling element
Central wiring set
mating connector
4H0973714 Flat contact housing with contact locking mechanism 8 pin 1
black
Possible single wire:
000979020E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 1,5
000979020EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 1,5
000979132E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
Flat male connector with detent lug 1,5
000979132EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+105C
Flat male connector with detent lug 1,5
000979254E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,5 X
-40C/+125C
Flat male connector with detent lug 1,5
8D0971273 Offers

[Name] [Note] [QTY]
Wiring harness for side lamp 1
clear glass
5N2937524 Offers

[Name] [Note] [QTY]
Wiring set for auxiliary heater rhd 1
PTC
5N1937524 Offers

[Name] [Note] [QTY]
Wiring set for auxiliary heater lhd 1
PTC
5N1937524B Offers

[Name] [Note] [QTY]
Wiring set for auxiliary heater lhd 1
for wire cross section: 10
for vehicles with additional electric air heater
5N2937524B Offers

[Name] [Note] [QTY]
Wiring set for auxiliary heater rhd 1
for wire cross section: 10
for vehicles with additional electric air heater
4B0937527 Offers

[Name] [Note] [QTY]
relay plate 6 pin 1
Possible single wire:
000979021E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
counterpart to: 000 979 022 E
000979021EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
000979133E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979133EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979144E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
flat connector/sleeve with retaining lug 1,0
6,3
000979236E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+125C
flat connector/sleeve with retaining lug 6,3
000979225E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+125C
flat contact 2,8
000979225EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat contact 2,8
000979306E 1 set single wires each with 2 contacts, in bag of 4 'Order qty. 4' 4,0 X
-40C/+125C
flat contact with retaining lug 4,8
000979405E 1 set single wires each with 2 contacts, in bag of 3 'Order qty. 3' 6,0 X
-40C/+105C
flat connector/sleeve with retaining lug 6,3
000979411E 1 set single wires each with 2 contacts, in bag of 3 'Order qty. 3' 6,0 X
-40C/+105C
flat contact 9,5
000979500AG Single lead with 1 contact in the bag 1500MM X
-40C/+105C
with cable crosssection: 10QMM
Cable colour: yellow
single wiring seal 3B0 972 744 A
000979500AH Single lead with 1 contact in the bag 1500MM X
-40C/+105C
with cable crosssection: 10QMM
Cable colour: yellow
000979500AJ Single lead with 1 silver- plated contact in the bag 1500MM X
-40C/+105C
with cable crosssection: 10QMM
Cable colour: yellow
single wiring seal 3B0 972 744 A
443937527 Offers

[Name] [Note] [QTY]
relay plate 9 pin 1
Possible single wire:
000979021E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
counterpart to: 000 979 022 E
000979021EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
000979023E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
with cable crosssection: 0,5
flat contact with retaining lug 4,8
000979114E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
flat connector/sleeve with retaining lug 1,0
6,3
000979133E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
with cable crosssection: 1,0QMM
flat contact 2,8MM
000979133EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979135E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
flat contact 1,0
4,8
000979212E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat connector/sleeve with retaining lug 6,3
000979225E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+125C
flat contact 2,8
000979225EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat contact 2,8
000979227E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
flat contact 2,5
4,8
000979227EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
flat contact 2,5
4,8
000979306E 1 set single wires each with 2 contacts, in bag of 4 'Order qty. 4' X
-40C/+125C
flat contact with retaining lug 4,0
4,8
000979405E 1 set single wires each with 2 contacts, in bag of 3 'Order qty. 3' 6,0 X
-40C/+105C
flat connector/sleeve with retaining lug 6,3
000979407E 1 set single wires each with 2 contacts, in bag of 3 'Order qty. 3' 6,0 X
-40C/+105C
flat contact with retaining lug 4,8
1K0972723A Offers

[Name] [Note] [QTY]
Flat contact housing 3 pin 1
Heater element for electr. auxiliary air heater black
Possible single wire:
000979027E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+105C
flat contact with retaining lug 4,8-6,3MM
000979027EC 1 set single wires each with 2 silver-plated contacts, in bag of 5 'Order quantity. 5' X
-40C/+125C
flat contact with retaining lug 0,5
4,8-6,3MM
000979152E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+105C
flat contact with retaining lug 4,8-6,3MM
000979152EC 1 set single wires each with 2 silver-plated contacts, in bag of 5 'Order quantity. 5' 1,0 X
-40C/+105C
flat contact with retaining lug 4,8-6,3MM
000979243E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+125C
flat contact with retaining lug 4,8-6,3MM
000979243EC 1 set single wires each with 2 silver-plated contacts, in bag of 5 'Order quantity. 5' X
-40C/+125C
with cable crosssection: 2,5
flat contact with retaining lug 4,8-6,3MM
000979308E 1 set single wires each with 2 contacts, in bag of 4 'Order qty. 4' 4,0 X
-40C/+105C
flat contact with retaining lug 4,8-6,3MM
000979308EC 1 set single wires each with 2 silver-plated contacts, in bag of 4 'Order qty. 4' X
-40C/+125C
with cable crosssection: 4,0
flat contact with retaining lug 4,8-6,3MM
000979425E 1 set single wires each with 2 contacts, in bag of 3 'Order qty. 3' 6,0 X
-40C/+125C
with cable crosssection: 6,0
flat contact 4,8-6,3MM
000979425EC 1 set single wires each with 2 silver-plated contacts, in bag of 3 'Order qty. 3' 6,0 X
-40C/+125C
with cable crosssection: 6,0
flat contact 4,8-6,3MM
1J0973202 Offers

[Name] [Note] [QTY]
Flat contact housing with contact locking mechanism 2 pin 1
level indicator
Possible single wire:
000979021E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
counterpart to: 000 979 022 E
000979021EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
000979133E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979133EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979225E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+125C
flat contact 2,8
000979225EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat contact 2,8
5N0971641 Offers

[Name]
wiring harness for centre console
1J0906029A Offers

[Name] [QTY]
bracket for connector housing 1
1J0919321 Offers

[Name] [Note] [QTY]
Flat contact housing 3 pin 1
Socket transparent
mating connector
357919321 Flat contact housing 3 pin "AUS" 1
Possible single wire:
000979023E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+105C
Flat male connector with detent lug 4,8
000979135E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact with retaining lug 4,8
000979227E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat contact with retaining lug 4,8
000979227EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat contact with retaining lug 4,8
000979306E 1 set single wires each with 2 contacts, in bag of 4 'Order qty. 4' 4,0 X
-40C/+125C
flat contact with retaining lug 4,8
000979407E 1 set single wires each with 2 contacts, in bag of 3 'Order qty. 3' 6,0 X
-40C/+105C
flat contact with retaining lug 4,8
1J0972712 Offers

[Name] [Note] [QTY]
Flat connector housing with contact locking mechanism 2 pin 1
black
Coupling element
Central wiring set
mating connector
1J0972923 Flat contact housing with contact locking mechanism 2 pin 1
black
Possible single wire:
000979022E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
000979022EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+105C
Flat male connector with detent lug 2,8
000979134E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+105C
Flat male connector with detent lug 2,8
000979134EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+105C
Flat male connector with detent lug 2,8
000979226E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+125C
Flat male connector with detent lug 2,8
000979226EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
Flat male connector with detent lug 2,8
3B0972732 Offers

[Name] [Note] [QTY]
Flat contact housing 4 pin 1
Coupling element
Central wiring set
mating connector
3B0972722 Flat contact housing 4 pin 1
black
Possible single wire:
000979020E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
flat contact 0,5
counterpart to: 1,5
000979020EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
flat contact 0,5
counterpart to: 1,5
000979132E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
flat contact with retaining lug 1,0
1,5
000979132EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
flat contact 1,0
(Copper wires galvanised) 1,5
000979254E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' X
-40C/+125C
flat contact 1,5
1,5
8K0973754 Offers

[Name] [Note] [QTY]
Flat contact housing 4 pin 1
AUX-IN socket black
mating connector
8K0972994 flat connector housing 4 pin 1
black
Possible single wire:
000979009E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
flat connector/sleeve with retaining lug 0,63
000979009EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
flat connector/sleeve with retaining lug 0,63
000979164E 1 set single wires (high temperature resistant) each with 2 contacts, in bag containing 5 items 'Order qty. 5' 0,75 X
1J0973722 Offers

[Name] [Note] [QTY]
Flat contact housing with contact locking mechanism 2 pin 1
black
Windscreen washer system pump
mating connector
8D0973822 Flat connector housing with contact locking mechanism 2 pin 1
Possible single wire:
000979021E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
counterpart to: 000 979 022 E
000979021EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
000979133E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979133EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979225E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+125C
flat contact 2,8
000979225EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat contact 2,8
5N1970039AN Offers

[Name]
part section wiring harness
For radiator fan
1K0906234 Offers

[Name] [Note] [QTY]
Flat contact housing 4 pin 1
Radiator fan black
Replacements: 1K0906234B
mating connector
1J0906444 flat connector housing 4 pin 1
Possible single wire:
000979027E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+105C
flat contact with retaining lug 4,8-6,3MM
000979027EC 1 set single wires each with 2 silver-plated contacts, in bag of 5 'Order quantity. 5' X
-40C/+125C
flat contact with retaining lug 4,8-6,3MM
000979152E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+105C
flat contact with retaining lug 4,8-6,3MM
000979152EC 1 set single wires each with 2 silver-plated contacts, in bag of 5 'Order quantity. 5' 1,0 X
-40C/+105C
flat contact with retaining lug 4,8-6,3MM
000979243E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+125C
flat contact with retaining lug 4,8-6,3MM
000979243EC 1 set single wires each with 2 silver-plated contacts, in bag of 5 'Order quantity. 5' X
-40C/+125C
with cable crosssection: 2,5
flat contact with retaining lug 4,8-6,3MM
000979308E 1 set single wires each with 2 contacts, in bag of 4 'Order qty. 4' 4,0 X
-40C/+105C
flat contact with retaining lug 4,8-6,3MM
000979308EC 1 set single wires each with 2 silver-plated contacts, in bag of 4 'Order qty. 4' X
-40C/+125C
with cable crosssection: 4,0
flat contact with retaining lug 4,8-6,3MM
000979425E 1 set single wires each with 2 contacts, in bag of 3 'Order qty. 3' 6,0 X
-40C/+125C
with cable crosssection: 6,0
flat contact 4,8
000979425E 1 set single wires each with 2 contacts, in bag of 3 'Order qty. 3' 6,0 X
-40C/+125C
with cable crosssection: 6,0
flat contact 4,8-6,3MM
000979425EC 1 set single wires each with 2 silver-plated contacts, in bag of 3 'Order qty. 3' 6,0 X
-40C/+125C
with cable crosssection: 6,0
flat contact 4,8-6,3MM
000979417E 1 set single wires each with 2 contacts, in bag of 3 'Order qty. 3' 6,0 X
-40C/+125C
with cable crosssection: 6,0
flat contact housing with retainer guide 9,5
000979500AA Single lead with 1 contact in the bag 1500MM X
-40C/+105C
with cable crosssection: 10QMM
Cable colour: yellow
single wiring seal 1K0 972 744
000979500AB Single lead with 1 contact in the bag 1500MM X
-40C/+105C
with cable crosssection: 10QMM
Cable colour: yellow
000979500AC Single lead with 1 silver- plated contact in the bag 1500MM X
-40C/+105C
with cable crosssection: 10QMM
Cable colour: yellow
1J0973722A Offers

[Name] [Note] [QTY]
Flat contact housing with contact locking mechanism 2 pin 1
black
Pump
headlight washer system
mating connector
1J0973822A Flat connector housing with contact locking mechanism 2 pin 1
dark brown
Possible single wire:
000979021E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
000979021EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
000979133E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979133EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979225E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+125C
flat contact 2,8
000979225EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat contact 2,8
6R0973735 Offers

[Name] [Note] [QTY]
Flat contact housing 10 pin 2
for headlamps black
Coupling element
Wiring set for engine
mating connector
1J0973835 Flat contact housing with contact locking mechanism 10 pin 1
Possible single wire:
000979021E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+105C
Flat male connector with detent lug 2,8
000979021EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+105C
Flat male connector with detent lug 2,8
000979133E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+105C
flat contact 2,8
000979133EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+105C
flat contact 2,8
000979225E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat contact 2,8
000979225EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat contact 2,8
1J0973737 Offers

[Name] [Note] [QTY]
Flat contact housing with contact locking mechanism 14 pin 1
black
Head light with gas discharge lamp
mating connector
1J0973837 Flat contact housing with contact locking mechanism 14 pin 1
Possible single wire:
000979019E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
flat contact 1,5
counterpart to: 000 979 020 E
000979019EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
flat contact 1,5
counterpart to: 000 979 020 EA
000979021E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
counterpart to: 000 979 022 E
000979021EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+125C
Flat male connector with detent lug 2,8
000979038EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
-40C/+105C
flat contact with retaining lug 1,5
000979038FA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 0,5 X
flat contact 1,5
(Copper wires galvanised)
000979131E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 1,5
000979131EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 1,5
000979133E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979133EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 1,0 X
-40C/+125C
flat contact 2,8
000979225E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+125C
flat contact 2,8
000979225EA 1 set single wires each with 2 gold-plated contacts, in bag of 5 'Order qty. 5' 2,5 X
-40C/+105C
flat contact 2,8
000979253E 1 set single wires each with 2 contacts, in bag of 5 'Order qty. 5' 1,5 X
-40C/+125C
flat contact 1,5

Lighting wiring harness

Assembly diagrams

Parts

Catalog

More

Contact us
