Блок управления дверью

[Name] [Note] [QTY]

Door control unit passenger side 1

mating connector

1K0972923 Flat contact housing with contact locking mechanism 6 pin 1

black

1K0971975 Flat contact housing with contact locking mechanism 20 pin 1

1K0972928 Flat contact housing with contact locking mechanism 16 pin 1

black

1J0972977D flat contact housing with cap 32 pin 1

blue

Locking mechanism violet

1J0972977H flat contact housing with cap 32 pin 1

blue

Locking mechanism orange

[Name] [Note] [QTY]

Door control unit driver side 1

mating connector

1K0972923 Flat contact housing with contact locking mechanism 6 pin 1

black

1K0971975 Flat contact housing with contact locking mechanism 20 pin 1

1K0972928 Flat contact housing with contact locking mechanism 16 pin 1

black

1J0972977D flat contact housing with cap 32 pin 1

blue

Locking mechanism violet

1J0972977H flat contact housing with cap 32 pin 1

blue

Locking mechanism orange

[Name] [Note] [QTY]

Window regulator motor left 1

mating connector

8Z0972703 Flat contact housing with contact locking mechanism 2 pin 1

[Name] [Note] [QTY]

Window regulator motor right 1

mating connector

8Z0972703 Flat contact housing with contact locking mechanism 2 pin 1

[Name] [Note] [QTY]

sound absorber (self-adhesive) 30X20X10MM 2

Window regulator motor

only to be used for: 8K0 959 801.A

8K0 959 802.A

[Name] [Note] [QTY]

Hexagon socket head panel bolt 5X15 6

[Name] [Note] [QTY]

Door control unit left a. right 2

mating connector

1K0971975 Flat contact housing with contact locking mechanism 20 pin 1

1K0972928 Flat contact housing with contact locking mechanism 16 pin 1

black

1K0972923 Flat contact housing with contact locking mechanism 6 pin 1

black

[Name] [Note] [QTY]

Window regulator motor left 1

mating connector

8Z0972703 Flat contact housing with contact locking mechanism 2 pin 1

[Name] [Note] [QTY]

Window regulator motor right 1

mating connector

8Z0972703 Flat contact housing with contact locking mechanism 2 pin 1

[Name] [Note] [QTY]

Hexagon socket head panel bolt 5X15 6
