- ARM,VLV RKR(INCLS 207,918) 12594509
- BOLT,CYL HD(M11X1.5X108) 11518953
- BOLT,CYL HD(M11X1.5X88)(MUST REPLACE BOLT WHEN REMOVED)(8.900) 11518992
- BOLT,HFH, M8X1.25X20,17THD,18 O.D.,10.9,7114M(IGN COIL) 11515756
- BOLT,HFH,M6X1X13,6 THD,14.2 OD,8.8,GMW3359,MAT POINT(MAP SEN) 11519964
- BOLT,HFH,M8X1.25X58,13.5 THD,GM500,REDUCED BODY,50C P POINT(PART OF 206)(0.349) 11609224
- BOLT,SPLG WIRE SUPT BRKT(M10X1.5X35,30 THD)(7.242) 11609632
- BOLT,VLV LFTR GDE RET(HFH W/8 DIA X 18.45 LG SHLDR,6X1X10 THD) 10166380
- BOLT,VLV RKR ARM CVR(W/WA & GROM)(PART OF 526)(INCLS 528) 11589120
- BRACKET,F/INJR WRG HARN CONN(**VPI 1-877-846-8243) 12590422
- BRACKET,SPLG WIRE SUPT 12578094
- CAP,OIL FIL(SAE 5W30, VENTED, W/SEAL)(INCLS 545)(ACDelco #FC219) 12589430
- CAP,VLV SPR 10166344
- CLIP,ENG WRG HARN 22729172
- COIL,IGN(MELCO, EXC BRACKET, BOLTS)(SEE GROUP 02.000 "SPARK PLUG WIRING" FOR DETAILED ILLUSTRATED VIEW)(ACDelco #D599A) 12595088
- COVER,VLV RKR ARM(INCLS 525,527,528,919,920)(INCLS CVR,BOLT,BAFFLE,GASKET) 12591710
- COVER,VLV RKR ARM(INCLS 525,527,528,919,920)(PCV ORFICE INTERGAL TO VALVE COVER AND IS NON-SERVICEABLE) 12590410
- GASKET KIT,CYL HD(INCLS 516,523,524)(USE T/W 4 #11561887 AND 4 #11588915) 89018138
- GASKET,CYL HD(*KIT1)(ACDelco #12589907) 12589907
- GASKET,VLV RKR ARM CVR(PART OF 526)(*KIT1) 10154775
- GUIDE,VLV LFTR(276MM) 10166364
- HEAD,CYL(INCLS 242-245)(USE T/W CORE PLUG ASM 24502262-QTY2) & SEALER 12345382 AS RQD) 19207868
- HEAD,CYL(INCLS 242-245)(USE T/W CORE PLUG ASM 24502262-QTY2) & SEALER 12345382 AS RQD) 19207867
- HEAD,CYL(INCLS VALVES)(INCLS 242-245)(REMANUFACTURED-NOT FOR SALE WHERE IMPORTS ARE RESTRICTED) 19210802
- HEAD,CYL(INCLS VALVES)(INCLS 242-245)(REMANUFACTURED-NOT FOR SALE WHERE IMPORTS ARE RESTRICTED) 19210801
- KEY,VLV STEM 10166345
- LIFTER,VLV(ACDelco #HL118) 17120070
- NUT,HFH,M8X1.25,17.9 OD,738 THK,13MM HEX,10, ZF(IGN COIL)(8.915)(ACDelco #11514596) 11514596
- PIN,CYL HD LOC(SPLIT,15X12.5,CHAM,STL) 14024244
- PLUG,CUP,1.014 OD,.32 THK,FROM .05 THK 304 STAINLESS.(PART OF 200)(0.293) 24502262
- ROD,VLV PUSH(EXHAUST) 12584951
- ROD,VLV PUSH(INTAKE) 12584950
- SCREW,PAN HD TAP,T#8-32X.3/8", O.D.,6010M,ZN OR ZN(PART OF 526) 09415952
- SEAL,OIL FIL TUBE(O RING)(PART OF 938)(27.94MM INNER DIAM)(1.758)(ACDelco #12593348) 12593348
- SEAL,VLV STEM OIL(STD)(*KIT1) 24508009
- SENSOR,ENG COOL TEMP(MATING CONN USE 88987993)(2WAY FEMALE)(ACDelco #213-4333) 12608814
- SPACER,VLV RKR ARM(PART OF 206)(0.010" THICK)(COLD ROLLED STEEL) 88894006
- SPARK PLUG,GAS ENG IGN(SPARK PLUG IS PRE-GAPPED,DO NOT CHANGE)(ACDelco #41-101)(IRIDIUM) 12568387
- SPRING,VLV 10166343
- STUD,HEX HD,W/SPL FLANGE,M10X1.5X17.5,M8X1.25X25, 14.5 OD,9.8 GMW3359(IGN COIL)(ACDelco #11588385) 11588385
- TUBE,OIL FIL(INCLS 939) 12582073
- TUBE,PCV(INCLS 901)(FOUL AIR) 12598160
- VALVE,EXH(STD) 12617048
- VALVE,INT(0.394 O.S.) 24506031
- VALVE,INT(STD) 12616697
- WIRE KIT,SPLG(SEE GROUP 02.000 "SPARK PLUG WIRING" FOR DETAILED ILLUSTRATED VIEW)(CONTAINS 6 WIRES)(ACDelco #746TT) 19351579
