Retrofit kit

[Name]

------------------------------ To convert/retrofit please observe the additional notes on the Audi ServiceNet ------------------------------

[Name] [Note] [Model info] [QTY]

1 set brake discs with brake pads front PR:1LT 1

repair set

4F0615301D Brake disc (vented) 314X25 5/112 2

8E0698151K 1 set: brake pads with wear indicator for disc brake 288X25MM 1

312X25MM

front

N 90876802 bolt,hex.hd.with shoul.(combi) M14X1,5X38 4

N 10648301 Hex socket countersunk bolt M6X16 2

[Name] [Note] [Model info] [QTY]

1 set brake discs with brake pads rear PR:1KD,2ED 1

Replacements: 4F0698601

repair set

4F0615601E Brake disc 302X12MM 5/112 2

4F0698451D 1 set of brake pads for disk brake 302X12MM 1

rear

N 91126801 ribbed bolt M12X1,5X62 4

N 10648301 Hex socket countersunk bolt M6X16 2

[Name] [Note] [QTY]

Retrofit kit 'S-LINE' 1

Sill trim strip (self-adhesive)

repair set

4F0853373E Sill trim strip left front 1

4F0853373K 01C Satin black

4F0853374E Sill trim strip right front 1

4F0853374K 01C Satin black

4F0853375E Sill trim strip left rear 1

4F0853375K 01C Satin black

4F0853376E Sill trim strip right rear 1

4F0853376K 01C Satin black

[Name] [Note] [Model info] [QTY]

1 set aerodynamic wiper blades lhd lhd 1

Replacements: 4F1998002A

repair set

4F1955425E Aero wiper blade 555MM 1

driver side

4F1955426B Aero wiper blade 562MM 1

passenger side

[Name] [Note] [QTY]

Retrofit kit for fire extinguisher lhd 1

also use: 4F0 860 997

Accompanying details: 4F0860997

[Name]

soul (black)

repair set

3D0860277 Fire extinguishers 1,0KG 1

8E0860985 Holder for fire extinguisher 1

8E0860296 retaining rail 1

8E0862263 Cover 1

8E0862263 4PK soul (black)

N 10597701 rivetted cap nut M5/0,5-3 4

N 91074201 Hexagon socket head bolt M5X16 4

N 90533005 hexagon head bolt (combi) M6X20 3

8E0012278 fitting instructions 1

[Name] [QTY]

Retaining bracket 1

[Name] [QTY]

Torch 1

[Name] [Note]

Torch

contents of package: 10

repair set

4F0947175 Torch 10

[Name] [Note] [QTY]

Retrofit kit cover cap for exterior mirror alu-look 1

For retrofitting

repair set

8E0857507D Mirror cap   left 1

8E0857507D 3Q7 aluminium

8E0857508D Mirror cap   right 1

8E0857508D 3Q7 aluminium

[Name] [QTY]

1 set attachment parts for bonnet 1

repair set

N 90798805 Hexagon collar nut M8 4

N 10347902 Hexagon socket head collared bolt (combi) M8X25 4

WHT001308 cap nut, self-locking M6 3

4F0823567 Clip 1

3W0971838 Cable ties 4,6X193 1

N 90653901 Retaining clip 16X7,6X3,2 1

1H0971939C terminal 1

N 90955801 bolt, hex. hd. (combi.) self-locking M6X25 4

3D0823429A Stop buffer 2

4B0823481 Stop buffer front 4

N 90325701 Bungs 14,5 2

4B0971847J Clip 1

8D0803583L Bungs 29,6 1

4E0955998 Grommet 1

[Name] [Note] [QTY]

attachment parts for one fender front 1

repair set

N 90949001 fillister head bolt (combi.) M6X21 4

N 90958902 Hexagon socket oval head bolt (combi) M6X16 14

N 91057001 oval head panel screw 5X16 2

N 90821401 expanding nut 4,8X19,6 2

N 91035501 double collared stud M6X25/M6X16 1

4A0805137A Retaining washer 2

N 90817302 rivetted cap nut M6/0,5-3 4

[Name] [Note] [QTY]

1 set attachment parts for wheel housing liner front 1

repair set

N 91057001 oval head panel screw 5X16 11

N 90821401 expanding nut 4,8X19,6 7

4A0805121A grip pin 2

4A0805121C grip pin 1

4A0805163 Clip 2

N 0385491 Spreader rivet 8X12 5

[Name] [Note] [QTY]

1 set fixing parts for bumper front 1

repair set

WHT001659 socket head hexagon bolt with cone M10X83 4

N 10286110 Hexagon collar nut self-locking M10 4

N 10617001 hexagon head bolt (combi) M8X80 4

N 10340103 Hexagon collar nut M8 8

N 90843202 hexagon head bolt (combi) M8X120X41 4

N 01508210 Hexagon collar nut M6 4

N 90967502 Hexagon socket head panel bolt 7X16 2

N 91067801 bolt,hex.hd.with shoul.(combi) M8X45 8

N 10124408 Hexagon socket head bolt (combi) M6X20 2

N 90346302 Pop rivet 4X18,8 4

N 90369405 Socket head bolt M6X20 2

N 10483102 Hex socket head bolt (combi) M6X50 2

4B0807467B Grommet 2

WHT001002 hex. nut with washer M6 2

N 90775801 Hexagon socket head panel bolt 4,8X19 6

431807300D expanding nut 6

N 90767602 Hexagon socket head panel bolt 6X12 6

8E0805960 Speed nut 3

N 90808503 Socket head bolt with inner multipoint head (Kombi) M6X25 1

[Name] [Note] [QTY]

1 set fixing parts for bumper rear 1

repair set

N 90775801 Hexagon socket head panel bolt 4,8X19 12

N 10617001 hexagon head bolt (combi) M8X80 2

N 90886602 Hexagon collar nut M8 2

N 90610003 hex. nut, self-locking with washer M10 2

N 10616801 hexagon head bolt (combi) M10X130 2

N 90772102 hexagon head bolt (combi) M10X105X45 4

4B0807467B Grommet 4

WHT001002 hex. nut with washer M6 4

N 90175205 Hexagon collar nut M6 2

N 10621301 expanding nut 5X13,2 8

N 90775001 Hexagon socket head panel bolt 4,8X16 2

N 10507301 expanding nut 5X15,3 6

N 90897401 Hexagon socket head panel bolt 5X16 6

N 10412804 Hexagon socket head panel bolt 5X16 6

8D0807300A expanding nut 10,3MM 6

N 90767602 Hexagon socket head panel bolt 6X12 6

N 90356203 Speed nut M5X16,6X17 6

4F0807739 Securing plate left a. right 2

N 90346302 Pop rivet 4X18,8 4

N 90708803 speed nut 5 4

[Name] [Note] [QTY]

Retrofit kit washer jets 3 point

F >> 4F-7-113 951 1

repair set

8J0955987G Spray nozzle, heated left 1

8J0955988G Spray nozzle, heated right 1

8E0955431 Adapter 2

Water jet

For vehicles with bonnet steel

4F0955431 Adapter 2

Water jet

For vehicles with bonnet aluminium

4F0012381 fitting instructions 1
